Intelligent Pre-charge Balancing BMS for Off-Grid Solar System

Name: Intelligent Pre-charge Balancing BMS for Off-Grid Solar System
Brand: Shenzhen First Tech Co., Ltd.
SKU: आरपीईएस-डब्लूएम2 (51.2वी 300एएच)
Price: 1255 USD
Availability: InStock

उत्पाद का विवरण

उत्पत्ति के प्लेस: चीन

ब्रांड नाम: 1stess

प्रमाणन: CE, IEC

मॉडल संख्या: आरपीईएस-डब्लूएम2 (51.2वी 300एएच)

दस्तावेज: 51.2V 314Ah 16kwh.pdf

भुगतान और शिपिंग की शर्तें

न्यूनतम आदेश मात्रा: 1 टुकड़ा

मूल्य: USD 1255 one piece

पैकेजिंग विवरण: कार्टन का डिब्बा

प्रसव के समय: 15 दिन

भुगतान शर्तें: एल/सी,टी/टी

आपूर्ति की क्षमता: प्रति माह 2000 टुकड़े

सबसे अच्छी कीमत पाएं

अब संपर्क करें

विनिर्देश

विवरण

विनिर्देश

प्रमुखता देना:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Intelligent Pre-charge BMS for solar, 51.2V 10kWh energy storage battery, Balancing BMS for off-grid system


संरक्षा विशेषताएं:	अधिभार संरक्षण, अधिभार संरक्षण, शॉर्ट सर्किट संरक्षण	क्षमता:	16kwh
रसायन विज्ञान:	लिथियम आयन	प्रमाणपत्र:	सीई, उल, आईईसी
चक्र जीवन:	> 5000 चक्र	गारंटी:	5-10 वर्ष
आकार:	740395250 मिमी	परिचालन तापमान:	-20°C से 55°C

संरक्षा विशेषताएं:	अधिभार संरक्षण, अधिभार संरक्षण, शॉर्ट सर्किट संरक्षण
क्षमता:	16kwh
रसायन विज्ञान:	लिथियम आयन
प्रमाणपत्र:	सीई, उल, आईईसी
चक्र जीवन:	> 5000 चक्र
गारंटी:	5-10 वर्ष
आकार:	740395250 मिमी
परिचालन तापमान:	-20°C से 55°C

विवरण

Intelligent Pre-charge Balancing BMS for Off-Grid Solar System

Key Features

Ultimate Safety: Utilizes high-safety LiFePO4 cells with rigorous international certifications
Extended Lifespan: Over 6000 cycles and 15-year design life for exceptional durability
Flexible Scalability: Supports up to 16 units in parallel for modular expansion up to 160kWh
Intelligent BMS: Built-in self-developed BMS with strong balancing and pre-charge, plus remote data & OTA upgrades
Compact & Flexible: Standard height with small footprint for flexible indoor floor mounting
Wide Compatibility: Works with most hybrid/battery inverters for self-consumption, backup, and off-grid uses
High Performance: 51.2V nominal voltage, 314Ah capacity, 16kWh energy, and 200A peak discharge current
Wide Operating Temperature: Supports -20℃ to 65℃ discharge with thermal derating for safety in varied climates

Technical Specifications

Model	WYLD51.2V314AH
Rated Voltage	51.2V
Rated Capacity	314Ah
Rated Energy	16.076kWh
Cycle Life	≥5000
Maximum Charging Voltage	57.4V
Minimum Discharge Voltage	43.2V
Standard Charging Current	150A
Standard Discharge Current	150A
Dimension LWH (mm)	740395250mm
Weight (kg)	115kg

Long Cycle Life and Durability

With over 6000 cycles at 90% depth of discharge (DoD) and a 15-year design life, the battery offers excellent longevity. This reduces the total cost of ownership and ensures reliable performance over decades, especially in daily cycling applications like solar self-consumption.

Manufacturer Overview

Shenzhen First Tech Co., Ltd was established in 2017 and is a one-stop solution provider of solar & battery energy storage systems. The company is engaged in the research, development, production, sales and service of commercial and industrial energy storage systems, home energy storage systems, lithium-ion battery packs, solar hybrid inverters, and solar optimizers.

Located in Shenzhen City, Guangdong Province, China, the factory has passed ISO9001, ISO14001, ISO45001 management system certification and products have obtained TUV-CB, CEIEC, EMC MSDS, UN38.3, and other certificates. Products are exported to clients in Europe, Africa, Middle East, North America, South America, Southeast Asia, and other regions.

In addition to providing standard products, First Tech welcomes OEM & ODM orders and provides professional service and quality products with competitive prices. The company is committed to becoming a global leading solar & ESS solution provider to provide green energy and contribute to a cleaner world.
